Description
The Ubiquiti Rocket M5 5GHz Hi Power 2×2 MIMO AirMax TDMA Station running 802.11n
The Airmax system is designed as a carrier class system and features
- Scalability: 300+ subs per sectored base station
- Latency: Latency remains low for voice and video applications as network scales
- Speed: 150Mbps+ PtMP performance
- Range: 50km+ outdoor range
The Rocket M5 is a rugged, hi-power, very linear 2×2 MIMO radio with enhanced receiver performance. It features incredible range performance (50+km) and breakthrough speed (150+Mbps real TCPI/IP). The device was specifically designed for outdoor PtP bridging and PTMP Airmax base-station applications.
Rocket M and AirMax BaseStation/Rocket Antennas have been designed to seamlessly work together. Installing Rocket M on AirMax BaseStation/Rocket Antennas requires no special tools, you simply snap it into place with the mount built into the Antennas.
This unit is supplied with PSU and POE injector and our fused UK mains lead.
Product Features:
- Airmax 802.11n
- Dual output
- Up to 150 Mbps throughput
Technical Specifications
| Ubiquiti Rocket M5 | |
|---|---|
| Processor | Atheros MIPS 24KC, 400MHz |
| Memory | 64MB SDRAM, 8MB Flash |
| Networking | 1 X 10/100 BASE-TX (Cat. 5, RJ-45) Ethernet Interf |
| TX Power | 802.11a 6-24Mbps 27 dBm |
| MCS0 27 dBm, MCS7 21 dBm | |
| Receive sensitivity | 802.11a 6-24Mbps -94dBm |
| MCS0-96 dBm, MCS7 -74 dBm | |
| Power Supply | 24V, 1A POE Supply Included (8 watts max) |
| RF Connector | 2x RPSMA (Waterproof) |
| Enclosure | Outdoor UV Stabilised Plastic |
| Mounting | Pole mount, j-clip supplied |
| Size | Enclosure Size 16cm length x 8cm width x 3cm heigh |
| Weight | 0.5 kg |
| Operating Temperature | -30C to 75C |
| Operating Humidity | 5 to 95% Condensing |
| Approvals | FCC Part 15.247, IC RS210, CE |
| RoHS | YES |
