Gigabit PoE Rackmount Switch

Please login or register to see price, or request a quote

The TL-SG1008PE is an 8-Port Gigabit Desktop/Rack mountable Switch with all 8 ports supporting the PoE+ standard. It provides a simple way to expand a wired network by transferring power and data over a single Ethernet Cable.

Power Over Ethernet

  • IEEE802.3af standards
  • Supports PoE power up to 15.4W for each PoE port
  • Supports priority function to protect the system when the system power is overloaded

High Performance

  • Auto MDI/MDIX
  • Auto-Negotiation
  • Store and forward
  • IEEE 802.3x flow control for Full-duplex Mode
  • Backpressure for Half-duplex Mode
  • 2k MAC address auto-learning and auto-aging
Compare
SKU: TL-SG1008PE Categories: , ,

Description

The TL-SG1008PE is an 8-Port Gigabit Desktop/Rack mountable Switch with all 8 ports supporting the PoE+ standard. It provides a simple way to expand a wired network by transferring power and data over a single Ethernet Cable. With a total power budget of 124W, up to 30W per port, TL-SG1008PE can power more high-powered devices such as wireless Access Points (APs), IP Cameras or IP Phones. Moreover, with innovative energy-efficient technology, the TL-SG1008PE can save up to 75% of the power consumption, making it an eco-friendly solution for your business network.

Features

•    Equipped with 8 PoE+ ports
•    Supports PoE+ standard with total power budget of 124W and up to 30W per port
•    Supports PoE+ IEEE 802.3af/at compliant devices
•    Supports IEEE 802.3x flow control for Full-duplex Mode and backpressure for Half-duplex Mode
•    8K entry MAC address table of the TL-SG1008PE with auto-learning and auto-aging
•    LED indicators to monitoring power, link, activity and speed
•    Internal power supply



How This Product Works

All 8 ports of TL-SG1008PE support Power over Ethernet Plus (PoE+) standard which can automatically detect and supply power to any IEEE 802.3af/at compliant device(s). In this situation, the electrical power is transmitted along with data in a single cable, allowing you to expand your network where there are electrical cables or outlets, where you wish to fix devices such as APs, IP Cameras or IP Phones.

Overload Arrangement

TL-SG1008PE has a priority function which helps protect the system when its power is overloaded. If all PoE+ devices’ power consumption is greater than or equal to 124W, a priority will be arranged among the 8 PoE+ ports, at which point the system will cut off the power of the lowest-priority port.

Port Priority Function

*Priority (port 1 > port 2 > port 3 > port 4 > port 5 > port 6 > port F > port 8): This function helps protect the system if the power becomes overloaded. For example, if port 1, 2, 4 and 7 are using 30W (maximum power per port is 30W, the system power is 120W in total), and there is an additional device inserted into Port 3 at 25W, the system will cut off the power of Port 7 in response to the power exceeding the 120W limit., This means Port 1, 2 and 4 will use 30W, and Port 3 will use 25W, with no power will be supplied to Port 7 as it has the lowest designated priority among the ports in use.

Easy To Use

TL-SG1008PE is easy to install and use. It requires no configuration or installation. With its Desktop/Rack mountable design, outstanding performance and quality, the TP-LINK TL-SG1008PE 8-Port Gigabit Desktop/Rack mountable Switch with 8-Port PoE is a great choice for expanding your home or office network.
