BLUSTREAM Digital to Analogue Converter (DAC) (DAC12AU)

Please login or register to see price, or request a quote

Our DAC12AU is designed to convert either Coaxial or Optical signals from a digital  signal to analogue stereo audio. The DAC12AU also includes a digital converter which converts Optical audio in to a Coaxial digital output. This provides the perfect cost effective solution when connecting the digital audio output from a TV display to an analogue input on an amplifier. The DAC12AU utilises 192kHz sample rates for enhanced sound reproduction.

Compare
SKU: DAC12AU Categories: ,

Description

Our DAC12AU is designed to convert either Coaxial or Optical signals from a digital  signal to analogue stereo audio. The DAC12AU also includes a digital converter which converts Optical audio in to a Coaxial digital output. This provides the perfect cost effective solution when connecting the digital audio output from a TV display to an analogue input on an amplifier. The DAC12AU utilises 192kHz sample rates for enhanced sound reproduction.

Key Features

  • DAC (Digital to Analogue audio Converter) converts either Optical or Coaxial digital to analogue stereo Left/Right audio output
  • Converts Optical digital audio input to Coaxial digital audio output
  • Auto-detects digital connection in use
  • Optical digital input has priority over Coaxial digital input
  • Outputs Coaxial digital and analogue L/R audio concurrently*
  • Supports sample rates 32 kHz, 44.1kHz, 48 kHz, 96 kHz & 192 kHz up to 24-bit resolution
  • Plug-and-play

* DAC12AU does not down mix Dolby / dts / multi-channel audio signals

Specifications

  • Audio Input Connectors: 1x Optical digital & 1x Coaxial RCA (SPDIF)
  • Audio Output Connectors: 2x Analogue stereo left/right & 1x Coaxial RCA (SPDIF)
  • Dimensions (W x H x D): 50mm x 26mm x 42mm
  • Dimensions including connections (W x H x D): 68mm x 26mm x 42mm
  • Shipping Weight: 0.4kg
  • Operating Temperature: 32°F to 104°F (0°C to 40°C)
  • Storage Temperature : -4°F to 140°F (-20°C to 60°C)
  • Power Supply: 5V/1A DC

Box Contents

1 x DAC12AU
1 x 5V/1A DC power supply
1 x Mounting kit
1 x User manual
