10/100 PoE Desktop Switch

Please login or register to see price, or request a quote

TL-SF1008P is an 8 10/100Mbps ports unmanaged switch that requires no configuration and provides 4 PoE (Power over Ethernet) ports. It can automatically detect and supply power with all IEEE 802.3af compliant Powered Devices (PDs).

Power Over Ethernet

  • IEEE802.3af standards
  • Supports PoE power up to 15.4W for each PoE port
  • Supports priority function to protect the system when the system power is overloaded

High Performance

  • Auto MDI/MDIX
  • Auto-Negotiation
  • Store and forward
  • IEEE 802.3x flow control for Full-duplex Mode
  • Backpressure for Half-duplex Mode
  • 2k MAC address auto-learning and auto-aging
Compare
SKU: TL-SF1008P Categories: , ,

Description

TL-SF1008P is an 8 10/100Mbps ports unmanaged switch that requires no configuration and provides 4 PoE (Power over Ethernet) ports. It can automatically detect and supply power with all IEEE 802.3af compliant Powered Devices (PDs). In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network to where there are no power lines or outlets, where you wish to ­fix devices such as APs, IP Cameras or IP Phones, etc.

Features

•    Supports PoE power up to 15.4W for each PoE port
•    Supports PoE power up to 57W for all PoE ports
•    Supports PoE IEEE 802.3af compliant PDs
•    Supports IEEE 802.3x flow control for Full-duplex Mode and backpressure for Half-duplex Mode
•    2K entry MAC address table of the TL-SF1008P with auto-learning and auto-aging
•    LED indicators for monitoring power, link, activity
•    External power adapter supply

Power over Ethernet

4 of the 8 Auto-Negotiation RJ45 ports (port-1 to port-4) of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af compliant Powered Devices (PDs).
-Overload Arrangement

TL-SF1008P has the priority function which will help protect the system when the system power is overloaded. If all PoE PDs power consumption is >= 57W, a priority will be arranged among the PoE ports, then the system will cut o‑ the power of the lowest-priority port.

-Port Priority Function

Priority (port-1=port-2=port-3>port-4):  This function will help to ensure the normal operation of the system, it means Port 4 will be cut off when all total PoE PDs power consumption exceed 57W. For an example, Port 1, 2 and 4 is using 15.4W (maximum power for per port is 15.4W); the system power is 46.2W in total. If there is an additional PD inserted to Port 3 with 12W, and then the system will cut off the power of Port 4 because of the overloaded power, this means Port 1, 2 will use 15.4W, and Port3 will use 12W, no power will be supplied to Port 4.

Easy To Use

TL-SF1008P is easy to install and use. It requires no confi­guration and installation. With desktop design, outstanding performance and quality, the TP-LINK’s TL-SF1008P 8-Port 10/100Mbps Desktop Switch with 4-Port PoE is an ideal choice for expanding your home or office network.
